The connection to an Intercomp S400 display is:
CS3000 S400
TXD (F) 2 (RXD)
GND (B) 7 (GND)
The connection to an Intercomp SA2000 display is:
CS3000 SA2000
TXD (F) 3
GND (B) 7
The connection to a 9-pin PC communication port is:
CS3000 PC 9-pin
TXD (F) 2
GND (B) 5
Note: For some setups it may be necessary to jump pins [6, 1, and 4] together, and pins
[7 and 8] together on the PC port connector.
The connection to a 25-pin PC communication port is:
CS3000 PC 25-pin
TXD (F) 3
GND (B) 7
Note: For some setups it may be necessary to jump pins [6, 8, and 20] together, and
pins [4 and 5] together on the PC port connector.
