37
COMMENT
► Shown examples are typical for
both parallel and concentric
clamping.
max. 250 mm
max. 1000 mm
max. 1000 mm
max. 250 mm
max. 250 mm
max. 250 mm
max. 500 mm
min. 3° (or 50mm/m)
Second element aer first elbow
Second element
aer first elbow
