Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 23
• Set keypad output 7 to activate continuous keypad buzzer sound, or output 8
to activate intermittent sound.
Siren outputs
The siren outputs on the Advisor Advanced control panel have addresses
starting from 1 (see Table 3 below).
On expanders with siren speaker outputs, output 16 is the siren output.
To enable the siren output, the programmed output must have the required
condition filter assigned (defined by an alarm event or a siren event, depending
on the preference settings). See “Filters, outputs, and triggers” on page 116 for
more details.
Default output assignments
The default output assignments are shown in Table 3 below.
Table 3: Default output assignments
Output
Name
Type
Default output function
Panel 1
S1
High current output
EN 50131 Grade 3: Internal siren output S1
VdS: External siren output S1
Panel 2
S2
High current output
EN 50131 Grade 3: External siren output S1
VdS: External siren output S2
Panel 3
S3
Low current output
A1 burglar alarm
Panel 4
S4
Low current output
A1 ready to set
Panel 5
S5
Low current output
A1 set
Keypad 7
—
Virtual
Continuous buzzer sound
Keypad 8
—
Virtual
Intermittent buzzer sound
Note: Output assignments may require adjustment to comply with EN 50131.
Zone and output addressing
Table 4 below shows the zone and output addressing in the Advisor Advanced
system.
Table 4: Zone and output numbering
Device
Zones
Outputs
Device
Zones
Outputs
Panel
1–8
1–8
2X ATS1810 relay
cards
—
17–24 [1]
Input expander
(ATS608)
9–16
N/A
Output expander
(ATS62x)
—
9–16
Expander 1
17–48
17–48
Keypad 1
—
1001–1008
Expander 2
49–80
49–80
Keypad 2
—
1009–1016
Expander 3
81–112
81–112
Keypad 3
—
1017–1024
Expander 4
113–144
113–144
Keypad 4
—
1025–1032
