Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 25
Specifications
For a list of panel models see “List of panel variants” on page vi.
Mains power specifications
Mains input voltage
230 VAC +10%, −15%, 50 Hz 10%
Current consumption at 230 VAC:
ATS1000A(-IP)
300 mA max.
ATS2000A(-IP)
500 mA max.
Transformer output:
ATS1000A(-IP)-SM/LP
20 VAC, 31 VA
ATSx000A(-IP)-MM
23 VAC, 58 VA
Power supply specifications
Power supply type
Type A per EN 50131-6
Power supply voltage
13.8 V 0.2 V
Power supply current:
ATS1000A(-IP)
1.1 A max. at 13.8 V 0.2 V
ATS2000A(-IP)
2.1 A max. at 13.8 V 0.2 V
Main board consumption:
ATSx000A
100 mA at 13.8 V ±0.2 V
ATSx000A-IP
150 mA at 13.8 V ±0.2 V
Maximum system current available [1]:
ATS1000A
1000 mA at 13.8 V ±0.2 V
ATS1000A-IP
950 mA at 13.8 V ±0.2 V
ATS2000A
2000 mA at 13.8 V ±0.2 V
ATS2000A-IP
1950 mA at 13.8 V ±0.2 V
Auxiliary power output (AUX. POWER) [2]
13.8 V 0.2 V, 1 A max.
Battery power output (BAT) [3]
13.8 V 0.2 V, 1 A max.
Battery type
Lead acid rechargeable, 7.2 Ah 12 V nom. (BS127)
or 18 Ah 12 V nom. (BS131) [4]
Maximum voltage at power supply, auxiliary
power output and battery power output
14.5 V
Battery low condition
From 9.5 V to 10.5 V
Battery test level [5]
11.2 V
Minimum voltage (battery recharging) at
power supply, auxiliary power output and
battery power output [6]
9.45 V
Maximum ripple voltage V, p-p [7]
100 mV typical, 300 mV max.
Overvoltage trigger value [8]
15.5 V min.
