26 Advisor Advanced ATSx000A(-IP) Installation and Programming Manual
[1] Current available for auxiliary power and battery charge outputs.
[2] Maximum permanent current to power devices external to the control equipment in the
absence of alarm conditions. The sum of the auxiliary and COMM power output current
cannot exceed the maximum current specified in “Auxiliary current and battery capacity” on
page 28.
[3] Battery output provides battery shortcut protection (according to VdS requirements).
[4] The specifications depend on the battery capacity. The above table gives BS127 and BS131
as an example.
[5] If during a manual or a programmed battery test the battery voltage drops below this
threshold, the battery test fails.
[6] A specific fail message is generated when any output fails.
[7] Max ripple voltage only when empty battery is charging.
[8] Overvoltage protection mechanism monitors the power supply voltage and shuts down the
PSU if the voltage raises above indicated value.
General features
Code combinations
From 10,000 (4 digits) to 10 billion (10 digits)
End-of-line resistor
1 kΩ, 1.5 kΩ, 2 kΩ, 2.2 kΩ, 3.3 kΩ, 3.74 kΩ,
4.7 kΩ (default), 5.6 kΩ, 6.8 kΩ, 8.2 kΩ, 10 kΩ
Onboard zones
8 (expandable to 16 with 1X ATS608)
Maximum zone number:
ATS1000A(-IP)
32
ATS2000A(-IP)
64
Onboard outputs
5 (expandable to 9 with 1X ATS624, or to 21 with 1X
ATS626).
See “Standard onboard outputs” on page 27.
Maximum output number
128
Areas:
ATS1000A(-IP)
4
ATS2000A(-IP)
8
Maximum keypad / RAS number
8
Maximum expander / DGP number
7
Maximum user number:
ATSx000A(-IP)
100
User groups
16
Event log capacity
500
Data retention (log, program settings)
20 years
Ethernet connection (IP only)
Supported standard
IEEE 802.3u
Speed
10BASE-T or 100BASE-TX
Duplex
Half-duplex and full-duplex
Cabling
FTP (foiled twisted pair) Cat 5e cable or better
Autonegotiation
MDIX
