Advisor Advanced ATSx000A(-IP) Installation and Programming Manual 71
• Part set 1-unset / Part set 2-unset: One badge partially sets or unsets areas.
Note: If the user privileges allow him to control doors, and “2.2.1.n.3.5.1 1 x door
access” on page 70 is set to Yes, the door access is also granted upon one-time
badge unset. If there are messages that require acknowledge, the access is
granted only after the acknowledgement.
2.2.1.n.3.5.4 3 x badge set
Three-time badge to set defines if the selected keypad allows you to set areas
with triple badge. The following values are available:
• Off: Triple badge does not cause any action.
• Set: Triple badge sets areas.
• Partset1 / Partset 2: Triple badge partially sets areas.
Notes
• This functionality works only if areas can be set with a card. See
“2.2.1.n.3.5.2 Card and PIN mode” on page 70 for available modes.
• This functionality is available only if the “2.2.1.n.3.5.3 1 x set/unset” option
described on page 70 is not configured as Set-Unset.
2.2.1.n.3.6 EE PIN lock
If the EE PIN lock option is set to Yes, it is not possible to use a PIN during the
entry time.
2.2.1.n.3.7 Isolate keypad
Use the Isolate keypad option to isolate the tamper fault events on the selected
keypad. The keypad, however, remains functional.
2.2.1.n.3.8 Buzzer silent
It is possible to disable the keypad buzzer for particular events. The following
options are available:
• Never: Buzzer operates normally. It is impossible to mute the buzzer using
X + Left volume control.
• During PS exit: Buzzer does not sound when part setting. The manual volume
control is available without limitations.
• Always: Buzzer is disabled. The manual volume control is available without
limitations.
