Radar Target Generator - RTG1002 Edition Date: 19-Apr-18
For the towertrack application: the checkbox Range Pulse Enable will create a TTL pulse on the grey BNC
every crossing of a 100m marker in the scenario relative to the radar.
The checkbox Ext TTL start scenario will make the target generator wait for a start event. This start for the
scenario will be generated by the motor when it is IN POSITION, in case of the towertrack application.
2.2.4. Scenario Definition Window
In order to define a scenario, click the Scenario definition button.
This window allows you to define the scenario of the flying target.
