Radar Target Generator - RTG1002 Edition Date: 19-Apr-18
RTG1002 Modulator 1 RTG 1002 Modulator 2
1 Tx beam 1 ; Rx beam 1 1 + 1 coverage 1 +1 coverage
2 Tx beam 2 ; Rx beam 2 2 + 2 coverage 2 + 2 coverage
3 Tx beam 1 ; Rx beam 1 & 2 1 + 1 coverage 1 + 2 coverage (= 2 + 1 coverage)
4 Tx beam 2 ; Rx beam 1 & 2 2 + 2 coverage 1 + 2 coverage (= 2 + 1 coverage)
5 Tx beam 3 ; Rx beam 1 & 2 3 +1 coverage 3 + 2 coverage
Table 1: Effect of VPD selector on the coverage and modulator settings
IE-UM-00601-005 RTG1002 User Manual.odt 38/48
