Invacare Action 3 NG Service Manual

3 4
SECTION 5—REAR WHEELS/FRONT CASTERS
R
eplacing/Repairing Rear Wheel & Front Caster
Tire/Tube
C A U T I O N
As with any vehicle, the wheels and tires should be checked periodically for cracks
and wear, and should be replaced when necessary.
FIGURE 5.7 Adjusting Rear Wheel Height

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
