SECTION 6—SEAT-TO-FLOOR HEIGHT
NOTE: To obtain the desired front seat to floor height, it will be necessary to perform
one or both following:
• Changing the caster size and/or mounting position on the fork, and/or seat angle
Refer to Removing/Installing/Repositioning the Caster Assemblies paragraph.
• Changing the fork size or adding/removing height adjustment spacers. Refer to
Adjusting Forks paragraph.
• Changing the rear wheel size. Refer to Removing/Installing Rear Wheels
paragraph.
• Changing the rear height positioning. Refer to Adjusting Rear Wheel Height
paragraph.
CHANGING SEAT-TO-FLOOR HEIGHT
Front Caster Position P1
Front Caster Position P2
Front
Seat
Height
Front caster
8" 6" 5.5" 5"
Caster
Position
Fork
Type
Wheel
Fixation
Caster
Position
Fork
Type
Wheel
Fixation
Caster
Position
Fork
Type
Wheel
Fixation
Caster
Position
Fork
Type
Wheel
Fixation
510 mm
P2
60
3
N/A
N/A
N/A
485 mm
P2
2
P2
40
3
P2
60 +
Spacer
3
460 mm
P1
2
P1
3
P1
3
P2
40
3
435 mm
N/A
P1
(3 holes)
2
P1
2
P1
(2 holes)
3
410 mm
P1
1
P1
1
385 mm
N/A N/A
P2
40 (Ultra
Low)
3
360 mm
P1
3
Front
Seat
Height
Rear Wheel/ Seat angle
20" 22" 24"
0°
3°
6°
0°
3°
6°
0°
3°
6°
510 mm
N/A
5
N/A
5
4
485 mm
5
4
5
4
3
460 mm
N/A
5
4
3
4
3
2
435 mm
4
3
2
3
2
1
410 mm
3
2
2
1
385 mm
3
2
N/A
1
N/A
360 mm
2
3

Invacare Action 3 NG Specifications

General

Frame Material	Aluminum
Weight Capacity	125 kg
Foldable	Yes
Crash Tested	Yes
Wheel Size	24 inches
Overall Width	58-70 cm
Front Casters	8 inches
Armrests	Optional
Footrests	Swing-away
Seat Width	380 - 530 mm
Seat Depth	40-50 cm
Seat Height	400 - 510 mm
