Invacare®EspritAction®4NG
3Componentsandtheirfunctions
3.1Overview
A
Pushhandle
B
Back
C
Rearwheelwithmotor
D
Parkingbrake(with22”/24”manualwheelsonly)
E
Frontwheelforkwithfrontwheel
F
Legrests,swiveling
G
Footrest
H
Frame
I
Seat
J
Armrest
K
Couplingring(bothwheels)
L
Controlunit
M
Joystick
N
Batterypack
Shortdescription
Thisisapoweredwheelchairwithcrossbarfolding
mechanismandswivelinglegrests.
Theequipmentofyourpoweredwheelchairmay
differfromthediagramaseachmobilitydeviceis
manufacturedindividuallytothespecicationsinthe
order .
