Invacare®EspritAction®4NG
4.TwodepthpositionsGarepossible,frontwardsor
backwards.
5.Performthesettingonbothsides,ifnecessary.
Adjustingthearmpadheight
1.LoosenthescrewBwith5mmAllenkeyattopofthe
armresttube.
2.Movethearmrestupwardsordownwardsuntilyou
reachthedesiredheight,whilekeepingscrewBin
place.
3.TightenthescrewB(5–6Nm).
4.Performthesettingonbothsides.
Adjustingthearmpaddepth
1.Loosenthe2screwsCbelowthearmpadbracket.
2.Movethearmpadfrontwardsorrearwardsuntilyou
reachthedesireddepth,whilekeepingscrewCin
place.
3.Tightenthe2screwsC(1,5–2Nm).
4.Performthesettingonbothsides.
Adjustingthesideprotectionheight
1.Loosenthe2screwsofthesideprotectionclampsE.
2.Movethesideprotectionupwardsordownwardsuntil
youreachthedesiredheight.
3.Tightenthe2screwsofthesideprotectclampsE
(0,7–1,2Nm).
4.Performthesettingonbothsides.
3.6Backrest
Therearethreetypesofbackrest(Fixed,Foldingand
Reclining)available.
3.6.1Backrestcover
Youcanadjustthetensionofthebackrestcoverasrequired.
Adjustingthebackrestcover
1.RemovethebackrestcushionA.
2.LoosentheVelcro®tapesBontherearofthebackrest
coverbysimplypullingonthem.
3.Tightenorloosenthetapesasrequiredthenreattach
them.
WARNING!
Riskoftipping
Ifthebandsaresetveryloose,thetippingpoint
ofyourwheelchairischangedfortheworse.
–Ensurethatthebandsaresetcorrectly.
IMPORTANT!
–Donotovertightenthebands;thisistoensure
thatthegeometryofthewheelchairisnot
changed.
24
1640502-B
