Componentsandtheirfunctions
Adjustingtheheight
1.LoosenwingscrewsCor/andD.
2.Adjustthecontrolunittothedesiredheight.
3.RetightenthewingscrewsCor/andD.
Swivellingtotheside
Yourmobilitydeviceisttedwithaswing-awaycontrolunit
holder,thenthecontrolunitcanbemovedawaytothe
side,forexample,todriveupclosetoatable.
3.5Armrests
WARNING!
Thearmrestdoesnotengageintothewheelchair.
–Thereforedonotholditinordertoliftthe
wheelchair.
CAUTION!
Riskofpinching
–Keepyourngersawayfrommovableparts
duringremoving,ttingoradjustingthe
armrest.
3.5.1Armrestremovable,widthanddepthadjustable
witharmpadheightanddepthadjustable
Removing
1.PreviouslypressonthelockingmechanismAlocatedat
thebottomofthearmrestverticalbracket.
2.Pullthearmrestbythearmcushionoutoftheholder .
3.Toadjusthoweasyordifcultitistopullthearmrest
outoftheholder,changethedegreetowhichthe
screwsDaretightened.
Fitting
1.Pushthearmrestintotheholder .
Adjustingthearmrestwidthanddepth(2positions)
1.LoosenthescrewFwith5mmAllenkeyatbottomof
thearmrestbracket.
2.Movethearmrestsidewardsuntilyoureachthedesired
width,whilekeepingscrewBinplace.
3.TightenthescrewF(8–9Nm).
1640502-B23
