Adjustingthelength
Theposturebelthasthegoodlength,whenthere’s
justsufcientspaceforaathandbetweenbody
andbelt.
1.ShortenorextendtheloopDasrequired.
2.ThreadloopDthroughcatchAandplasticbuckleE
untiltheloopisat.
Ifthisadjustmentisnotsufcient,itmightberequiredto
re-ttheposturebeltatthexations.
Fittingtheposturebeltatthexations
CAUTION!
–Threadthebeltloopthroughbothplastic
bucklestoavoidthebeltfromloosening.
–Dotheadjustmentsonbothsidesequally,
sothatthebuckleclaspremainsinacentral
position.
–Makesurethatthebeltsdonotgetcaughtin
thespokesofarearwheel.
1.ThreadtheloopFthroughthexationonthechairG
andthenthroughBOTHplasticbucklesH.
4.2Headrest
Theheightandtheremovalareoperatedbythe
handwheel.Thebarisequippedwithanadjustable
stopblock.
Heightadjustment
341640502-B
