Invacare®EspritAction®4NG
Unfoldingthebackbrace
1.FoldthebackbraceBupwards.
2.AlignthebackbraceBwiththepushhandleandpushit
downonthehandscrewA.
3.FirmlytightenthehandscrewAandmakesurethat
theTWOhandscrewsAareproperlytightened.
Itisimportanttoensurethatthebackbraceis
correctlyttedandengagedatalltimeswhenthe
chairisinuse.Itshouldnotbelefthangingloose
(seelabelConthebackbrace).
3.8Legrests
WARNING!
Riskofinjury
–Neverliftthewheelchairbythefootrest
supportsorlegrests.
CAUTION!
Riskofpinching
–Keepyourngersawayfrommovableparts
duringfolding,disassemblingoradjustment.
IMPORTANT!
Riskofdamagetothelegrestmechanism
–Donotplaceanythingheavy,orletchildren
sitonthelegrest.
3.8.1Swivelinglegrests
Swiveling
1.ActivatethereleaseleverAandswivelthelegrests
totheoutside.
Swivelingforwards
1.Swivelthelegrestforwardsuntilitengages.
Unhinging
1.ActivatethereleaseleverA.
2.Pullthelegrestupwards.
Hinging
1.Hingethelegrestonthefrontoftheframeandswivel
itforwardsuntilitengages.
