Componentsandtheirfunctions
IMPORTANT!
–Onlyevertightenthebandswhenthe
wheelchairisunfolded.
Asimplebackrestcoverisavailableforallbackrest
types.Thesecoversarenotadjustable.
3.6.2Backrestcoverheight
Theheightofthebackrestcovercanbeadjustedon
therecliningbackpostsonly.Theadjustmentmust
becarriedoutbyanauthorizeddealer.
3.6.3Foldingbackrest
Tosavespacefortransportingthewheelchair,thebackrest
canbefolded.
Foldingandunfoldingthebackrest
1.OperateleverAbypullingitandfoldthetopofthe
backrest.
2.Toreturntotheinitialposition,bringthetopinthe
verticalposition;itlocksautomatically.
3.6.4Angleadjustablebackrest(-15°/+15°)
Theangleofthebackrestcanbeadjustedfrom–15°to
+15°(stepless).
1.Adjustthebackrestanglethankstotheadjustablescrew
A.
2.Turn5mmAllenkeyclockwisetoobtainanegative
angle.
3.Alternatively,turn5mmAllenkeyunderclockwiseto
obtainapositiveangle.
4.Ensurebothadjustmentstothedesiredangleareequal
onbothsides.
Invacarerecommendsthatthebackrestangleadjustmentis
carriedoutbyanauthorizeddealer.
