Accessories
1.LoosenthescrewinthestopblockB.
2.LoosenthehandwheelA.
3.Adjusttheheadresttothedesiredposition.
4.Re-tightenthehandwheelAdowntothetopofthe
headrestattachment.
5.SlidethestopblockB.
6.Re-tightenthescrew.
Itisnowpossibletoremovetheheadrestand
reinsertitinthedesiredpositionwithoutfurther
adjustments.
Depth/angleadjustment
1.LoosenthehandleD.
2.LoosenthescrewsC.
3.Adjustthedepthandangleoftheheadrest.
4.Re-tightenthehandleandthescrews.
4.3HeadrestJunior
Theheight;depthandangleadjustmentsare
operatedbythecombinationoftheheadrestscissor
bracketsposition.
Height;depthandangleadjustment
1.LoosenthehandleA.
2.LoosenthescrewsBwith5mmAllenkey.
3.Adjusttheheight;depthandangleoftheheadrestby
movingthescissorbracketstothedesiredposition.
4.Re-tightenthehandleAandthescrewsB(5–6Nm).
1640502-B35
