Invacare Esprit Action 4 NG User Manual

Invacare®EspritAction®4NG
6Controlssystem
6.1Controlsprotectionsystem
Thewheelchaircontrolssystemisttedwithanoverload
protection.
Ifthedriveisseverelyoverloadedoveralongperiodoftime
(forexample,whendrivingupasteephill)andespecially
whentheambienttemperatureishigh,thecontrolssystem
couldoverheat.Inthiscase,thewheelchairperformanceis
graduallyreduceduntilitcomestoahalt.Thestatusdisplay
showsacorrespondingerrorcode(refertoControlunitand
Quickassistanceonsystemfailurechapters,ALBEResprit
usermanual).Byswitchingthepowersupplyoffandback
onagain,theerrorcodeisclearedandthecontrolssystem
isswitchedbackon.Itcanhowevertakeuptoveminutes
untilthecontrolssystemhascooleddownenoughforthe
drivetorestorefullperformanceagain.
Ifthedriveisstalledbyaninsurmountableobstacle,for
example,acurborsimilarwhichistoohigh,andthedriver
attemptsdrivingformorethan20secondsagainstthis
obstacle,thecontrolssystemautomaticallyswitchesoffto
preventthemotorsfrombeingdamaged.Thestatusdisplay
showsacorrespondingerrorcode(refertoControlunitand
Quickassistanceonsystemfailurechapters,ALBEResprit
usermanual).Byswitchingoffandbackonagain,theerror
codeisclearedandthecontrolssystemisswitchedbackon.
Adefectivemainfusemaybereplacedonlyafter
checkingtheentirecontrolssystem.Yourauthorized
dealermustperformthereplacement.Youcannd
informationonthefusetypein10TechnicalData,
page63.
6.2Batterypack
Powerissuppliedby12Vbatterypack.Thebatteriesare
maintenance-freeandonlyneedregularcharging.
Youcanndinformationonhowtocharge,handle,
transport,store,maintain,andusebatteries,refertoBattery
packchapter,ALBERespritusermanual.
