Invacare®EspritAction®4NG
4.4Manualpropulsion(22”or24”wheels)
Themanualpropulsionallowstodriveandsteerthe
wheelchairbyusingthehandrims.
WARNING!
Riskofoverturning
Iftheremovableaxleofarearwheelisnotfully
engaged,thewheelcanbecomelooseduring
use.Thiscanleadtooverturning.
–Alwaysensurethattheremovableaxlesare
fullyengagedwheneveryoutawheel.
Removingthecontrolunitandthepowered12”rear
wheels
Thebatterypackonlyneedstoberemovedwhen
thewheelchairrequiresfoldingfortransportation.
Thebatterypackcanremainonthewheelchairin
manualpropulsionmode.
1.Switchoffthepowerbuttonofthecontrolunit.
2.Removethecontrolunitfromitsarmrestbracket,
looseningwingscrewA,referto3.4Controlunit
adjustments,page22.
3.Disconnecttheplugfromthecontrolunit,referto
Controlunitchapter,ALBERespritusermanual.
4.Removethepowered12”rearwheels,referto7.6
Removingandttingthepowered12”rearwheels,
page55.
5.Toretrotfrommanualpropulsionmodetopower
mode,reversethisprocedure.
Fittingtherearwheels
1.Releasethebrakes.
2.Withonehand,holdthewheelchairupright.
3.Withtheother,holdthewheelthroughtheexternal
spokerimaroundthewheelhub.
4.Usingyourthumb,presstheremovableaxlebuttonA
andholditdown.
5.PushtheaxleintotheadaptersleeveBuptothestop.
6.Releasetheremovableaxlebuttonandmakesurethat
thewheelissecure.
Removingtherearwheels
1.Releasethebrakes.
2.Withonehand,holdthewheelchairupright.
3.Withtheother,holdthewheelthroughtheexternal
spokerimaroundthewheelhub.
361640502-B
