Invacare®EspritAction®4NG
Calfpadadjustment
ThecalfpadEswingsawayduringtransfersandhasheight
adjustmentoptions.
Heightadjustment:
•Version1
1.AfterlooseningthexingscrewBadjusttothe
desiredheightandrmlytightenthexingscrew.
•Version2
1.AfterlooseningthexingscrewCadjusttothe
desiredheightandrmlytightenthexingscrew.
ThecalfpadEhasthreedepthadjustmentoptions.
•Version2only
1.Afterlooseningthexingboltadjusttothedesired
depthandrmlytightenthexingbolt.
Invacarerecommendsthatdepthadjustmentiscarriedout
byanauthorizeddealer .
Footplateadjustment
Therearethreedifferentfootplatesavailable.
•Heightadjustablefootplates,version1
1.LooseningthexingboltBwith10mmspanner
orhandscrewC.
2.Adjustintooneoffourpresetpositionsandtighten
thexingbolt(5Nm)BorhandscrewCintothe
desiredposition.
•Heightadjustablefootplates,version2
1.LooseningthexingscrewBwith5mmAllenkey.
2.Adjustintooneoffourpresetpositionsandtighten
thexingscrew(5Nm)Bintothedesiredposition.
•Height,angleanddepth(iftted)adjustablefootplates
1.LooseningthescrewFwith5mmAllenkey.
2.Adjustintotheangleanddepth(iftted)positions
andrmlytightenthescrew(12Nm)Fintothe
desiredposition.
Invacarerecommendsthatfootplateadjustmentiscarried
outbyanauthorizeddealer .
Toensureagoodpositionofthefeet,twotypes
ofstrapscanbeprovided;theheelstrap(serial)
andthecalfstrap(optional)attachedtothelegrest
support.BothadjustablebyVelcro®fasteners.
3.9Anti-tipperALBERandstandard
Ananti-tipperpreventsthewheelchairfromtipping
backwards.
IfyourwheelchairisequippedwithALBERanti-tippers(with
jack-upfunction),refertoAnti-tipperschapter,ALBEResprit
usermanual.
WARNING!
Riskofoverturning
Anti-tippersthatareincorrectlysetornolonger
workingcanleadtooverturning.
–Alwayscheckthattheanti-tipperisworking
beforeusingthewheelchairandhaveitset
orreadjustedbyanauthorizeddealerwhen
required.
301640502-B
