Componentsandtheirfunctions
WARNING!
Riskofoverturning
Onunevenorsoftground,theanti-tippercansink
intopotholesordirectlyintotheground,thereby
curtailingoreliminatingitssafetyfunction.
–Onlyusetheanti-tipperwhentravellingon
evenandrmground.
Activatingtheanti-tipper
1.ReleasethespringbuttonAandswiveltheanti-tipper
sidewardsuntilitengages.
2.EnsurefrontreleasebuttonAprotrudesfullythrough
framehole.
WARNING!
Riskoftipping
Anactivatedanti-tippercancatchwhen
negotiatingasteporanedge.
–Alwaysdeactivatetheanti-tipperbeforedriving
overasteporkerb.
Deactivatingtheanti-tipper
1.ReleasethespringbuttonAandswiveltheanti-tipper
sidewardsuntilitengages.
WARNING!
Riskofoverturning
–Alwaysadvisetheuserifyoudeactivatethe
anti-tippers.
Thereisalabelonthehousingoftheanti-tipper,
thislabelshowswhentheanti-tipperisinactivated.
Whentheanti-tipperiscorrectlyactivated,thelabel
willbeconcealed.
Settingtheheight
WARNING!
Riskofoverturning
–Theadjustmentsoftheanti-tippermustbe
carriedoutbyanauthorizeddealer.
Thisadjustmentisrequiredwithreferencetothe
positionanddiameteroftherearwheelaswellas
theuserconditionsandhisparticularsafetylimits.
Makesurethattheanti-tipperdeviceistted
correctlyoneachside,thespringbuttonAand
xationBmustbelockedintoposition.
