Transport
IMPORTANT!
–Applytheposturebeltofthe3-pointpassenger
restraintsystemlowacrossthepelvisso
thattheangleoftheposturebeltiswithin
thepreferredzone(A)of30°to75°tothe
horizontal.Asteeperangleispreferred,but
neverexceeding75°.
A
30°
75°
7.4Disassemblingthewheelchairfortransport
Todisassembleandfoldthewheelchairtogetherfor
transport,proceedasfollows:
1.Removethelegrests,referto3.8Legrests,page28.
2.Removethebatterypack,refertoBatterypackchapter,
ALBERespritusermanual.
3.Foldthewheelchairtogetherandloadit,referto7.4.1
Foldingandunfoldingthewheelchair,page53.
7.4.1Foldingandunfoldingthewheelchair
Foldingthewheelchair
1.Removetheseatcushion,ifpresent.
2.Foldthebackbrace,ifpresent.
3.Foldthefootplatesupwards.
4.Pulltheseatcoverupwards.
