InvacarEspritAction®4NG
Fitposturebelt
WARNING!
Theposturebeltcanbeusedinadditiontobut
neverasasubstituteforanapprovedpassenger
restraintsystem(3-pointbelt).
1.Adjustposturebelttotthewheelchairoccupant,see
section4.1Posturebelt,page33.
Fasteningthe3-pointpassengerrestraintsystem
IMPORTANT!
Theillustrationabovemaydifferdependingon
therestraintsystemsupplier.
WARNING!
Ensurethe3-pointpassengerrestraintsystem
tsastightlyacrosstheuser'sbodyaspossible
withoutdiscomfortandnopartistwisted.
Ensurethe3-pointpassengerrestraintsystemis
notheldawayfromtheuser'sbodybypartsof
thewheelchairsuchasarmrestsorwheelsetc.
Ensuretheuserrestrainthasaclearpath
fromtheusertotheanchorpointwithout
interferencebyanypartofthevehicle,
wheelchair,seatingoraccessory.
Ensuretheposturebelttssnuglyoverthe
occupantspelvisandisnotallowedtorideup
intotheabdominalarea.
Ensuretheuserisabletoreachtherelease
mechanismunaided.
1.Attachthe3-pointpassengerrestraintsystemreferring
totheusermanualsuppliedwithyour3-pointrestraint
system.
521640502-B
