Componentsandtheirfunctions
WARNING!
Riskofinjury
–Alwaysmaketheseadjustmentsbeforethe
usersettlesdowninthewheelchairtoprevent
injuries.
–Invacarestronglyrecommendstheuse
ofanti-tippers(availableasanoption)in
combinationwithallrearwheelpositionswhen
youuseyourbackrestwithanangleof12°
andmore
IMPORTANT!
–Pushonthebackrestcanesbeforeoperating
thelevers,thisistoreleasetheauto-locked
securitysystem.
1.Releasetheauto-lockedsystembypushingonthe
backrestcanes.
2.SimultaneouslypulltheleversAtoprovidesthesame
angleonbothsides.
3.Releasetheleverswhenyoureachthedesiredangle.
3.7Standardbackbraceforthebackrest
Thebackbracelinksthetwopushhandles,providestension
tothebackrestupholsteryandmustalwaysbeinposition
onreclinerversions.
CAUTION!
–Donotusethebackbracetopushthe
wheelchair.Thebackbraceisnotapushbar!
–Donotattempttoliftthewheelchairusing
thebackbrace;itmaycomelooseanditcould
break.
–Keepyourngersawayfrommovableparts
andsharpedgestopreventinjuries.
Foldingthebackbrace
1.SlightlyloosenthetwohandscrewsA,pullupthe
backbraceBandswivelitdownwardsalongthe
backrest(onrightorlefthand).
2.FoldthebackbraceBuntilitisinverticalposition.
1640502-B
27
