Accessories
4.6Tray
CAUTION!
Riskofinjuryormaterialdamageifamobility
devicewhichisttedwithatrayistransported
inavehicle
–Ifatrayistted,alwaysremoveitbefore
transportingthemobilitydevice.
4.6.1Adjusting,removing,swingingthetray
Adjustingwidthofthetray
1.Loosenwing-screwA.
2.Adjusttraytowardstheleftorright.
3.Re-tightenwing-screwA.
Adjustingdepth,removingthetray
1.Loosenwing-screwB.
2.Adjusttraytodesireddepth(orremoveitentirely).
3.Re-tightenwing-screwB.
Swingingawaythetray
Thetraycanbeswivelledupandawaytothesidetoallow
theusertogetinandoutofthemobilitydevice.
CAUTION!
Riskofinjury!Whenthetrayisraiseditdoes
notlockinplaceinthisposition!
–Donottiltthetrayupandleaveitleaningin
thisposition.
–Neverattempttodrivewiththetraytiltedup.
–Alwayslowerthetrayinacontrolledmanner .
4.7Caneholder
WARNING!
Riskofoverturning
–Ensurethatthecaneholderdoesnotproject
beyondtheexternaldiameteroftherear
wheel.
1640502-B39
