Invacare Robin Service Manual

Invacare®Robin™
1.Liftthehoistslightlyandpushthesuspensionpinoutofits
holderinthetrolley.
2.Turnthehoistby90degreesandpullitoutofthetrolley.
Removethetrolleyfromtherail
1.Removetheendstop.
2.Slidethetrolleyoutoftherail.
3.2.2DismountingRobinMover™
1.Pulltheemergencystraptopreventaccidentalactivationofthe
ceilinghoistafterithasbeendismountedfromtherail.
2.Removetheendstop.
3.Slidethewheelsofthehoistoutoftherail.
4.Installtheendstop.
Tightentheboltto30Nm.
5.Ifremovingthehoistfromtherailmotor,performthefollowing
steps:
Whenreplacingthebatteryorperformingservice,itis
alsonecessarytoremovethehoistfromtherailmotor.
101586747-A
