3.3Replacingthehandcontrol
1.SlideandholdlockingleverAawayfromtheapertureC.
2.PulltheplugBoutoftheaperture.
3.Insertplugofthenewhandcontrolintoaperture.Makesure,
theplugisinthecorrectorientationwiththeslotupwards(see
image).
4.ReleaseleverA,sothatthegateclosesandholdtheplugin
theaperture.
3.4Removingthehoistcover
Beforeremovingthehoistcover,pulltheredemergencystraptoturn
offthehoistandremovethehoistfromthetracksystem.Referto:
•3.2Dismountingtheceilinghoist,page9
Tools:Screwdriver,slotted
1.RemoveprotectioncapsA.Usefingersor,ifrequired,usea
screwdrivercarefully.
2.UntightenscrewsB,usingascrewdriver.
3.RemovethecoverCfromthehoist.
Toclosethehoistcover,tightenthescrewsandattachtheprotection
capsagain.
3.5ReplacingStrapandHookAssemblies
Tools:10mmsocketkey;5mmhex/Allenkey
1.Withtheceilinghoistinthetrack,lowerthestrapstotheir
lowestpointusingthehandcontrol.
2.Pulltheredemergencystraptoperformanemergencystop.Do
notperformemergencylowering.
3.Removehoistfromtrack.Referto3.2Dismountingtheceiling
hoist,page9.
4.Removethecover.Referto3.4Removingthehoistcover,page
12
.
12
1586747-A
