Invacare Robin Service Manual

Invacare®Robin™
3.11ReplacingtheTwinSpeedSwitch
CAUTION!
StaticelectricitycandamagethePCBsinsidethehoist.
Beforeworkingintheinsideofthehoist:
–Pulltheredemergencystraptoturnoffthehoist.
–Removethehoistfromthetracksystem.(Referto3.2
Dismountingtheceilinghoist,page9
)
–Removethecoverfromthehoist.(Referto3.4
Removingthehoistcover,page12
)
–Ananti-staticmatmustbeusedwhenworkinginside
theceilinghoist.
T10Torxscrewdriver
1.Placethehoistonasurface(suchasthecornerofatable)sothat
thehoistissupportedyetthestrapsandhandcontrolarefree
hanging.Ensurethehoistissafeandcannotslip/fallofthetable.
2.RemovethetwoyellowcablesAfromthetwinspeedswitchB.
3.RemovethetwoscrewsC.
4.AttachthenewtwinspeedswitchwithscrewsC.Connectthe
yellowcablesA.Ensure,theyareconnectedtothebottomand
topterminals.
5.Re-assemblethehoistandresettheemergencystop.
3.12ReplaceContactDiscforRobinMover™
CAUTION!
StaticelectricitycandamagethePCBsinsidethehoist.
Beforeworkingintheinsideofthehoist:
–Pulltheredemergencystraptoturnoffthehoist.
–Removethehoistfromthetracksystem.(Referto3.2
Dismountingtheceilinghoist,page9
)
–Removethecoverfromthehoist.(Referto3.4
Removingthehoistcover,page12
)
–Ananti-staticmatmustbeusedwhenworkinginside
theceilinghoist.
Screwdriver
181586747-A
