3.Usingacloth,protectthesolenoidplungerwhilstclampingwith
gripsatthesametime.
Usinga7mmspannerraisethenutAbyturninganti-clockwise
2completeturns.
4.Fortesting,restrainthehoistwithonehandwhilstpressingthe
LeftorRightbuttononthehandcontrol.
Thereshouldbegoodcontactbetweenthewhitedrivewheel
andtheundersideofthetrack.Ifnot,repeatstep3.
5.Reassembletheplasticshells.Ensurethecorrectorientation,
withclearancefortheplateabovethesolenoidtomoveupand
downfreely.Seeimagesinstep2.
3.10AdjustingLooseStrapSwitch
CAUTION!
StaticelectricitycandamagethePCBsinsidethehoist.
Beforeworkingintheinsideofthehoist:
–Pulltheredemergencystraptoturnoffthehoist.
–Removethehoistfromthetracksystem.(Referto3.2
Dismountingtheceilinghoist,page9
)
–Removethecoverfromthehoist.(Referto3.4
Removingthehoistcover,page12
)
–Ananti-staticmatmustbeusedwhenworkinginside
theceilinghoist.
2mmAllenkey
161586747-A
