Invacare Robin Service Manual

Invacare®Robin™
4.PluginthewiresA.
5.Re-assemblethehoistandresettheemergencystop.
3.7ReplacingthePCB(PrintedCircuitBoard)
CAUTION!
StaticelectricitycandamagethePCBsinsidethehoist.
Beforeworkingintheinsideofthehoist:
–Pulltheredemergencystraptoturnoffthehoist.
–Removethehoistfromthetracksystem.(Referto3.2
Dismountingtheceilinghoist,page9
)
–Removethecoverfromthehoist.(Referto3.4
Removingthehoistcover,page12
)
–Ananti-staticmatmustbeusedwhenworkinginside
theceilinghoist.
1.Removethebattery.Refertosteps1and2inchapter3.6
Replacingthebattery,page13
.
2.RemoveallplugsB,C,D,EandFfromthePCBA.
3.ReleasethePCBAfromtheretainingholdersbygentlypressing
downthelockingclipsandleveringthePCBslightlyawayfrom
thechassisplate.
4.LiftthePCBuptoremove.
5.PlacethenewPCBintothechassisandpressitslightlyagainst
thechassisplateuntiltheretainingholderssnapintoplace.
6.ConnecttheplugsB,C,D,EandFtothenewPCB.
7.Re-insertbattery,re-assemblethehoistandresettheemergency
stop.
14
1586747-A
