Invacare Robin Service Manual

Service
3.8Replacingthefuse
CAUTION!
StaticelectricitycandamagethePCBsinsidethehoist.
Beforeworkingintheinsideofthehoist:
–Pulltheredemergencystraptoturnoffthehoist.
–Removethehoistfromthetracksystem.(Referto3.2
Dismountingtheceilinghoist,page9
)
–Removethecoverfromthehoist.(Referto3.4
Removingthehoistcover,page12
)
–Ananti-staticmatmustbeusedwhenworkinginside
theceilinghoist.
1.Removethehandcontrol.Refertochapter3.3Replacingthe
handcontrol,page12
2.Removethebattery.Refertosteps1to3inchapter3.6
Replacingthebattery,page13
.
3.GentlypullthefuseAstraightoutawayfromtheholderB.
4.Insertnewfuse.
Makesureonlyafusewithcorrectrating10A250V
slowblowisused.
5.Re-insertbattery,re-assemblethehoist,insertthehandcontrol
andresettheemergencystop.
3.9Adjustingthesolenoiduntilthehoist
traverses
RobinMover™only.
4mmAllenkey;7mmspanner
1.Pulltheredemergencystrap.
2.Withtheceilinghoistremainingonthetrack,removeboth
plasticshells:
a.Removethescrewssecuringtheplasticshellsfromtherail
motor.
b.Pulltheplasticshellsawayfromeachothertoremovethem
fromtherailmotor.
1586747-A15
