Technicaldata
6Technicaldata
6.1Therailsystem
Allrailprofilesaremanufacturedinextrudedaluminium.
Therailsareavailablewithwhitepowdercoating.
Therailsareavailableinthreedifferentheights;S=68mm,M=114
mmandL=183mm,providingafeespanof2m,4mand8m,
respectively.
Theprofilewidthofallthreeprofilesis58mm.Thetopofthe
profilesareshapedtopermitthecouplingoftherailstothe
installationbrackets.
Ondelivery,therailforthehoistwillfeatureamilledgrooveon
itsbottom.Thisgrooveisusedforhoistinstallationandiscalled
keyhole.
Possibleinstallations
Singlerailcanbeinstalledontheceilingorontothewalland
floor.Therailpositionintheroomcanbeeitherparalleltoawall
orangularinrelationtoawall.
Thetraversesystemcanbeinstalledontheceilingorontothe
wallandfloor.Thefreespanbetweenthetwoparallelrailscanbe
upto8000mm.
CurvesareavailableintheS-profileandcanbeinstalledonthe
ceiling.Theyareavailableinanglesof30°,45°,60°and90°.
Specialsolutions
Installationwithpendlingbracketsisusedinthefollowingcases:
Whentheheightoftheceilingvariesinthelengthwisedirectionof
therail,orwhentherailistobecountersunk.
Angularinstallationisusedwhentherailhastobeinstalledin
otheranglesthan90°.
6.2Dimensionsandweight
Dimensions
Robin™
Robin
Mover™
Hoistlength(A)470mm470mm
Hoistwidth(B)250mm250mm
Hoistheight(C)203mm266mm
Maximumliftingrange(D)2.5m2.5m
Weights
Robin™
Robin
Mover™
Maximumliftingcapacity(Safe
WorkingLoad)
200kg200kg
Totalweightwithoutsling
7.3kg10kg
1586747-A29
