5.Resettheemergencystopbypressingtheresetbutton.
6.CheckthatthestrapAiscompletelyunwoundasshowninthe
image.Ifnot,windthestrapsoutusingtheUP/DOWNbutton
onthehandcontrol.
7.AlignthestrapretainingboltsBwiththeapertureinthechassis
usingtheUP/DOWNbuttononthehandcontrol.
8.Pulltheredemergencystrapagain.
9.Removestrapbolts,usinga10mmsocketkeyanda5mm
hex/Allenkey.
10.Removethestrapthroughguidecylinder.
11.Insertanewstrapthroughguidecylinderandassembleusingthe
strapretainingbolts(Torque:4Nm).Makesurethatthenew
strapisfedovertheslackstrapswitchwire.
12.Re-mountthecover,re-assemblethehoisttothetrackand
resettheemergencystop.
3.6Replacingthebattery
CAUTION!
StaticelectricitycandamagethePCBsinsidethehoist.
Beforeworkingintheinsideofthehoist:
–Pulltheredemergencystraptoturnoffthehoist.
–Removethehoistfromthetracksystem.(Referto3.2
Dismountingtheceilinghoist,page9
)
–Removethecoverfromthehoist.(Referto3.4
Removingthehoistcover,page12
)
–Ananti-staticmatmustbeusedwhenworkinginside
theceilinghoist.
1.UnplugthewiresA.
2.RemovethebatterypackB.
3.Insertanewbatterypack.
UseonlyInvacarerecommendedbatteries.
