Invacare Robin Service Manual

Troubleshooting
5.5TakingVoltageReadings
ReadFeedingVoltage
Takebatteryvoltagefeeding
PCB.
Expectedresult:23to29V
Takevoltagefeedingmain
switch(twomiddlepins)
Expectedresult:23to29V
Takevoltagefeedingthelift
motorwhilstpressingtheUP
orDOWNbuttononthehand
control.
Expectedresult:23to29V
ReadFeedingVoltage
Takevoltagefeedingthehoist
moverPCB.(RobinMover™
only)
Expectedresult:23to29V
Takevoltagefeedingthecopper
ringswhilstpressingtheLEFT
orRIGHTbuttononthehand
control.(RobinMover™only)
Expectedresult:23to29V
Takevoltagefeedingthetrolley
moverPCBwhilstpressingthe
LEFTorRIGHTbuttononthe
handcontrol.(RobinMover™
only)
Expectedresult:23to29V
1586747-A27
