14 | Optidrive P2 User Guide | Version 3.00 www.invertekdrives.com
3.5.3. IP66 Units
ON
OFF
PWR
Drive
Size
A B D E F G H I J Weight
mm in mm in mm in mm in mm in mm in mm in mm in mm in kg Ib
2 257 10 .12 220 8.66 200 7. 87 29 1.12 239 9. 41 188 7.40 178 7. 01 4.2 0 .17 8.5 0.33 4.8 10.6
3 310 12.20 277 10.89 252
9.90
33 1. 31 266 10.47 211 8.29 200 7. 87 4.2 0 .17 8.5 0.33 7. 7 16.8
Mounting Bolts Tightening Torques
Frame Size Metric UNF Frame Size Required Torque
2 M4 #8 Control Terminals All 0.5 Nm 4.5 lb-in
3 M4 #8 Power Terminals 2 & 3 1 Nm 9 lb-in
3
Mechanical Installation
