Invertek Drives Optidrive ODP-2 User Manual

Version 3.00 | Optidrive P2 User Guide | 75www.invertekdrives.com
11
Troubleshooting
Fault
Code
No. OLED Message
Description
Corrective Action

12 Communications Fault Communications lost with PC or remote keypad. Check the cables and connections to external
devices.

13 Excessive DC ripple The DC Bus Ripple Voltage level can be displayed in parameter P0-16.
A historical log is stored at 20ms intervals prior to a trip in parameter P0-37.
Check all three supply phases are present and within the 3% supply voltage level imbalance
tolerance.
Reduce the motor load.
If the fault persists, contact your local Invertek Drives Sales Partner.

14 Input phase loss Drive intended for use with a 3 phase supply, one input phase has been disconnected or lost.
 
15 Instantaneous over
current on drive output
Refer to fault 3 above.

16 Faulty thermistor on
heatsink
Refer to your Invertek Sales Partner.

17 Internal memory fault Parameters not saved, defaults reloaded.
Try again. If problem recurs, refer to your IDL Authorised Distributor.

18 4-20mA Signal Lost The reference signal on Analog Input 1 or 2 (Terminals 6 or 10) has dropped below the minimum
threshold of 3mA. Check the signal source and wiring to the Optidrive terminals.

19 Internal memory fault Parameters not saved, defaults reloaded.
Try again. If problem recurs, refer to your IDL Authorised Distributor.

20 User Parameter Default User Parameter defaults have been loaded. Press the Stop key.

21 Motor PTC Over
Temperature
The connected motor PTC device has caused the drive to trip.

22 Cooling Fan Fault Check and if necessary, replace the drive internal cooling fan.

23 Ambient Temperature
High
The measured temperature around the drive is above the operating limit of the drive.
Ensure the drive internal cooling fan is operating.
Ensure that the required space around the drive as shown in sections 3.5 to 3.9 has been observed,
and that the cooling airflow path to and from the drive is not restricted.
Increase the cooling airflow to the drive.
Reduce the effective switching frequency setting in parameter P2-24.
Reduce the load on the motor / drive.

24 Maximum Torque Limit
Exceeded
The output torque limit has exceeded the drive capacity or trip threshold.
Reduce the motor load, or increase the acceleration time.

25 Output Torque Too Low Active only when hoist brake control is enabled P2-18 = 8. The torque developed prior to releasing
the motor holding brake is below the preset threshold. Contact your local Invertek Sales Partner for
further information on using the Optidrive P2 in hoist applications.

26 Drive output fault Drive output fault.

29 Internal STO circuit Error Refer to your Invertek Sales Partner.

30 Encoder Feedback Fault Encoder communication /data loss.

31 Speed Error Speed Error. The error between the measured encoder feedback speed or the estimated rotor
speed is greater than the pre-set limit allowed.

32 Encoder Feedback Fault Incorrect Encoder PPR count set in parameters.

33 Encoder Feedback Fault Encoder Channel A Fault.

34 Encoder Feedback Fault Encoder Channel B Fault.

35 Encoder Feedback Fault Encoder Channels A & B Fault.

40 Autotune Failed Measured motor stator resistance varies between phases. Ensure the motor is correctly connected
and free from faults. Check the windings for correct resistance and balance.

41 Measured motor stator resistance is too large. Ensure the motor is correctly connected and free
from faults. Check that the power rating corresponds to the power rating of the connected drive.

42 Measured motor inductance is too low. Ensure the motor is correctly connected and free from
faults.

43 Measured motor inductance is too large. Ensure the motor is correctly connected and free from
faults. Check that the power rating corresponds to the power rating of the connected drive.

44 Measured motor parameters are not convergent. Ensure the motor is correctly connected and free
from faults. Check that the power rating corresponds to the power rating of the connected drive.

45 Incorrect Supply Phase
Sequence
Applies to Frame Size 8 drives only, indicates that the incoming power supply phase sequence is
incorrect. Any 2 phases may be swapped.
