CHV180 series frequency inverter special for elevator Appendix D
.134.
Function
Code
Name Description
Factory
Setting
Mod
ify
LCD Display
P1.20
Motor autotuning
deceleration
0.001~10.000 m/s
2
0.600m/s
2
◎
MOTOR
AUTOTUNIN
G DECEL
P1.21
Emergence running
speed
0.000~P0.02 m/s 0.300m/s
◎
EMERGENCE
RUNNING
ACCEL
P1.22
Emergence running
acceleration/decelerat
ion
0.001~10.000 m/s
2
1.000m/s
2
◎
EMERGENCE
RUNNING
DECEL
P1.23
Forced deceleration
speed 1
P1.25~10.000 m/s
2
1.000m/s
2
◎
FORCED
DECELERATI
ON DECEL 1
P1.24
Forced deceleration
speed 1 detection
0.0~P1.26 20.0% ◎
FORCED
DECELERATI
ON
SPEED 1
CHECK
P1.25
Forced deceleration
speed 2
P1.27~P1.23 m/s
2
0.900m/s
2
◎
FORCED
DECELERATI
ON DECEL 2
P1.26
Forced deceleration
speed 2 detection
P1.24~P1.28 40.0% ◎
FORCED
DECELERATI
ON
SPEED 2
CHECK
P1.27
Forced deceleration
speed 3
0.001~P1.25 m/sP
2
P
0.700m/s
2
◎
FORCED
DECELERATI
ON DECEL 3
P1.28
Forced deceleration
speed 3 detection
P1.26~100.0% 80.0% ◎
FORCED
DECELERATI
ON
SPEED 3
CHECK
P1.29 Stop mode selection
0: Deceleration to stop
1: Coast to stop
1 ◎
STOP MODE
