CHV180 series frequency inverter special for elevator Appendix D
.135.
Function
Code
Name Description
Factory
Setting
Mod
ify
LCD Display
P1.30~
P1.31
Reserved 0~65535 0 ◎
RESERVE
P2 Group: Motor parameters
P2.00 Motor model
0:
asynchronous
motor
1: synchronous motor
0 ◎
INVERTER
MODEL
P2.01
Wheel diameter of
traction motor
100~2000mm 500mm ◎
TRACTION
MOTOR
WHEEL DIA
P2.02 Reduction ratio 1.00~100.00 30.00 ◎
SPEED-DOW
N RATE
P2.03
Hoist rope hanging
ratio
1~8 1 ◎
TOW
HANGING
RATE
P2.04 Motor rated power
0.4~900.0kW
Depend on
model
◎
MOTOR
RATE
POWER
P2.05 Motor rated frequency
0.01Hz~P0.04 50.00Hz
◎
MOTOR
RATE FREQ
P2.06 Motor rated speed
1~36000rpm
1460
rpm
◎
MOTOR
RATE SPEED
P2.07 Motor rated voltage
1~460V 380V ◎
MOTOR
RATE VOLT
P2.08 Motor rated current
0.1~1000.0A
Depend on
model
◎
MOTOR
RATE CURR
P2.09
Motor rated power
factor
0.05~1.00 0.86 ◎
MOTOR
RATE
POWER
FACTOR
P2.10 Motor stator resistor
0.001~65.535Ω
Depend on
model
○
STATOR
RESISTOR
P2.11 Motor rotor resistor
0.001~65.535Ω
Depend on
○
ROTOR
