INVT CHV180-004G-4 User Manual

CHV180 series frequency inverter special for elevator Appendix D
.137.
Function
Code
Name Description
Factory
Setting
Mod
ify
LCD Display
P3.09 ACR integral gain I
0~65535 500 ○
ACR I
P3.10
Slip compensation
rate of drive side
50.0~200.0% 100% ○
DRIVE SLIP
COMP
P3.11
Slip compensation
rate of trig side
50.0~200.0% 100% ○
TRIG SLIP
COMP
P3.12 Torque upper limit
0.0~200.0%(rated
current of inverter)
150.0%
○
TORQUE
LIMIT
P3.13~
P3.14
Reserve function 0~65535 0 ◎
RESERVE
FUNCTION
P4 Group: Encoder parameter
P4.00
Encoder type
selection
0: Increment encoder
1: SIN/COS encoder
2: UVM encoder
1 ◎
ENCODE
TYPR
P4.01 PG pulse number 1~65536 1000 ◎
TORQUE
BOOST
P4.02 PG direction selection
0: forward
1: reverse
0 ◎
BOOST
CUT-OFF
P4.03
Magnetic pole initial
position
0.00~360.00 0.00 ◎
POLE INITIAL
POSITION
P4.04
Thread break
detection time of
encoder low speed
0.0~100.0s
(0.0 means don’t
detect)
1.0 ◎
THREAD
BREAK
DETECTION
T1
P4.05
Thread break
detection time of
encoder high speed
0.0~100.0s
(0.0 means don’t
detect)
1.0 ◎
THREAD
BREAK
DETECTION
T2
P4.06
Reverse detection
time of encoder
0.0~100.0s
(0.0 means don’t
detect)
1.0 ◎
REVERSE
DETECTION
TIME
P4.07
Magnetic p
ole position
amplitude gain
0.50~1.50 1.00 ◎
POLE
POSITION
