CHV180 series frequency inverter special for elevator Appendix D
.138.
Function
Code
Name Description
Factory
Setting
Mod
ify
LCD Display
AMP PLUS
P4.08
C phase pole position
offset
0~1024 512
C POLE
POSITION
OFFSET
P4.09
D phase pole position
offset
0~1024 512
D POLE
POSITION
OFFSET
P4.10
Synchronous motor
static identification
current
10.0%~150.0% 50.0%
P4.11~
P4.13
Reserved 0~65535 0
P5 Group: Input terminals
P5.00
Terminal input mode
selection
0~0x3FF 0
INPUT MODE
P5.01
Terminal function
input selection
0: Invalid
1: Valid
0
INPUT
SELECTION
P5.02 S1 Terminal function
0:Invalid
1: Up running
2: Down running
3: Examine running
4: Emergency running
5: Free stop
6: Fault reset
7: Exterior fault input
8~10: Multi-speed
terminals 1~3
11~13: Uplink forcing
deceleration 1~3
14~16: Downlink
forcing deceleration
1~3
1
S1
FUNCTION
P5.03 S2 Terminal function
2
S2
FUNCTION
P5.04 S3 Terminal function
8
S3
FUNCTION
P5.05 S4 Terminal function
9
S4
FUNCTION
P5.06 S5 Terminal function
3
S5
FUNCTION
P5.07 S6 Terminal function
0
S6
FUNCTION
P5.08 S7 Terminal function
0
S7
FUNCTION
P5.09 S8 Terminal function
0
S8
