INVT CHV180-004G-4 User Manual

CHV180 series frequency inverter special for elevator Appendix D
.145.
Function
Code
Name Description
Factory
Setting
Mod
ify
LCD Display
P7.13
Previous two fault
type
0: Not fault
1: IGBT Ph-U
fault(OUT1)
2: IGBT Ph-V
fault(OUT2)
3: IGBT Ph-W
fault(OUT3)
4: Over-current when
acceleration(OC1)
5: Over-current when
deceleration(OC2)
6: Over-current when
constant speed
running (OC3)
7: Over-voltage when
acceleration(OV1)
8: Over-voltage whe
deceleration(OV2)
9: Over-voltage when
constant speed
running(OV3)
10: DC bus
Under-voltage(UV)
11: Motor overload
(OL1)
12: Inverter overload
(OL2)
13: Input phase failure
(SPI)
14: Output phase
failure (SPO)
15: Rectify overheat
(OH1)
●
3rd LATEST
FAULT
P7.14 Previous fault type
●
2nd LATEST
FAULT
P7.15 Current fault type ●
CURRENT
FAULT
