INVT CHV180-004G-4 User Manual

CHV180 series frequency inverter special for elevator Appendix D
.144.
Function
Code
Name Description
Factory
Setting
Mod
ify
LCD Display
P7.07
Stop state display
selection
BIT0: Reference
speed
BIT1: Reference
frequency
BIT2: DC bus voltage
BIT3: Input terminal
state
BIT4: Output terminal
state
BIT5: Motor poles
BIT6: AI1
BIT7: AI2
BIT8: Pole position
BIT9: ~BIT15:
Reserved
0x00FF
○
STOP
DISPLAY
P7.08
Rectifier module
temperature
0~100.0℃ ●
RECTIFIER
TEMP
P7.09
IGBT module
temperature
0~100.0℃ ●
IGBT TEMP
P7.10 MCU software version
Factory setting ●
MCU
VERSION
P7.11 DSP software version
Factory setting ●
DSP
VERSION
P7.12
Accumulated running
time
0~65535h ●
TOTAL RUN
TIME
