INVT CHV180-004G-4 User Manual

CHV180 series frequency inverter special for elevator Appendix D
.151.
Function
Code
Name Description
Factory
Setting
Mod
ify
LCD Display
PA.04
Communication
timeout delay
0.0(invalid)
0.1~100.0s
0.0s ○
COM
TIMEOUT
PA.05
Communication reply
enabled selection `
0: Enabled
1: Disabled
0 ○
RESPONSE
ACTION
PA.06
Reserved 1~127 1 ◎
RESERVE
PA.07
Reserved 0~6 4 ◎
RESERVE
PA.08~
PA.11
Reserved 0~65535 0 ◎
RESERVE
Pb Group: Display monitor
Pb.00 Running frequency
0.0~Maximum
frequency
Pb.01 Reserved 0~65535
Pb.02 Pole position angle
0.0~359.9
Pb.03
Synchronizer static
identify actual current
value
0.0%~200.0%
Pb.04 Mechanical angle 0.0~359.9
Pb.05 Reserved Reserved
Pb.06
AD detection value of
encoder C phase
0~1024
Pb.07
AD detection value of
encoder D phase
0~1024
Pb.08~Pb.
09
Reserved Reserved
RESERVE
PC Group: No weighing starting parameters
PC.00
No weighting
compensation enable
0:Disable
1:Enable
0
PC.01
Load compensation
time
0.000~5.000s 0.500s
PC.02
Load compensation 0.000~5.000s 0.300s
