CHV180 series frequency inverter special for elevator Detailed function description
.37.
Function
Code
Name Description
Setting
Range
Factory
Setting
P1.03
Multi-step
speed 3
0.000~P0.02 0.000~P0.02
0.000m/s
P1.04
Multi-step
speed 4
0.000~P0.02 0.000~P0.02
0.000m/s
P1.05
Multi-step
speed 5
0.000~P0.02 0.000~P0.02
0.000m/s
P1.06
Multi-step
speed 6
0.000~P0.02 0.000~P0.02
0.000m/s
P1.07
Multi-step
speed 7
0.000~P0.02 0.000~P0.02
0.000m/s
Multi-step speed is defined by P1.00~P1.07. The 8-step speed will be come ture by the
combination of 3 multi-step speed terminals. The detailed description is as follow:
Multi-step speed
terminal 3
Multi-step speed
terminal 2
Multi-step speed
terminal 1
Speed Setting
Function
code
OFF OFF OFF Multi-step speed 0
P1.00
OFF OFF ON Multi-step speed 1
P1.01
OFF ON OFF Multi-step speed 2
P1.02
OFF ON ON Multi-step speed 3
P1.03
ON OFF OFF Multi-step speed 4
P1.04
ON OFF ON Multi-step speed 5
P1.05
ON ON OFF Multi-step speed 6
P1.06
ON ON ON Multi-step speed 7
P1.07
Function
Code
Name Description
Setting
Range
Factory
Setting
P1.08
Start quadric
acceleration
0.001~10.000 0.001~10.000
0.350m/sP
3
P
P1.09
Start
acceleration
0.001~10.000 0.001~10.000
0.700m/sP
2
P
P1.10
Speed-down
quadric
deceleration
0.001~10.000 0.001~10.000
0.350m/sP
3
P
