INVT iMars MG Series User Manual

INVT iMars MG series grid-tied solar inverters Display panel
Setting item LCD display Instruction
Set power
set power
P-Lmt
Mode
LmtPower
P.Factor
Limit Mode： Invalid
Invalid
Auto
Manual
Limit Power
100%
Power Factor
Grid Tied Mode
Normal Mode
Power Factor： 1.00
Input password
0000
The password is needed when enter into
the interface of “Set power”. Get the
password from the supplier if necessary
(supplier password: 2678). There are 3
submenus: ①P-Lmt Mode: invalid
(limited power function is invalid),auto
(special for single phase) ,manual (set
the limit of output value manually); ②
LmtPower: this function is only valid
when the P-Lmt Mode is manual, the
percentage is that of the rated power and
the setting range is from 10% to 100%;
③p.Factor: includes normal model
(default value “1”), current advanced
mode and current hysteresis mode and
the setting rage is -0.9-0.99.
(the machine of three phase only has the
function of ③)
Personal
Personal
MPP Start Volt
MPPT Volt
120V
Input password
0000
This function is only valid for single
phase inverters. The password is
needed when enter into the personal
interface. Get the password from the
supplier if necessary (supplier password:
2678). It can set MPPT starting voltage
from 120V to 160V under the submenu
of ”MPPT start volt”.
