INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Product overview
‐6‐
Symbol Instruction Naming instance
7R5: 7.5kW
011: 11kW
015: 15kW
022: 22kW
……
⑥ Rated speed
A: 1000rpm
B: 1500rpm
E: 2000rpm
F: 2500rpm
G: 3000rpm
⑦ Voltage class
2: 220VAC
4: 380VAC
⑧ Encoder type
1: 2500-PPR standard incremental type
3: 17-bit single-turn absolute value
(1)
4: 17-bit multi-turn absolute value
7: Rotary transformer
9: 23-bit multi-turn absolute value
⑨
Shaft end
connection
A: solid with threaded hole and key (standard)
B: Solid optical axis
⑩ Optional part
0: with oil seal but no brake
1: without oil seal or brake
(3)
2: with oil seal and permanent magnet brake
3: without oil seal but with permanent magnet brake
(3)
4: with oil seal and electromagnetic brake
5: without oil seal but with electromagnetic brake
(3)
⑪ Lot no. Manufacturer lot no.
(4)
Remark:
(1)
: 17-bit absolute single turn motor belongs to a separate series and its dimension and parameters
are different. Only electromagnetic brake is used. Please pay attention to corresponding series when
selecting models;
(2)
: 40-base motor, only supports 2500-PPR and 17-bit absolute encoder;
(3)
: Non-stock up model, the ordering cycle will be delayed for 3~5 days;
(4)
: No need to fill in for the first-time model selection by customers;
In addition, the non-17 bit single-turn absolute motor with 40 or 60 bases supports permanent magnet
brake only.
