INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Product overview
‐10‐
1.3.6 Naming of motor braking cables
Symbol Instruction Naming instance
① Product series BRKL: motor brake cable
② Cable length
03: 3m
05: 5m
10: 10m
30: 30m
③ Plug on motor end
A: 2PIN metal plug
B: 3PIN regular aviation plug
C: 3PIN metal plug
1.4 Braking resistor specification
Drive model
Embedded braking
resistor
Min. resistance of external
braking resistors
SV-DA200-0R1-2 / 60Ω
SV-DA200-0R2-2 / 60Ω
SV-DA200-0R4-2 / 60Ω
SV-DA200-0R7-2 30Ω 60W 30Ω
SV-DA200-1R0-2 30Ω 60W 30Ω
SV-DA200-1R5-2 30Ω 60W 20Ω
SV-DA200-2R0-2 15Ω 120W 15Ω
SV-DA200-3R0-2 15Ω 120W 15Ω
SV-DA200-4R4-2 15Ω 120W 15Ω
SV-DA200-1R0-4 60Ω 60W 60Ω
SV-DA200-1R5-4 60Ω 60W 60Ω
SV-DA200-2R0-4 60Ω 60W 40Ω
SV-DA200-3R0-4 60Ω 60W 30Ω
SV-DA200-4R4-4 30Ω 120W 30Ω
SV-DA200-5R5-4 30Ω 120W 30Ω
SV-DA200-7R5-4 / 30Ω
SV-DA200-011-4 / 20Ω
SV-DA200-015-4 / 15Ω
SV-DA200-022-4 / 10Ω
