INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Faults and solutions
‐135‐
P3.90
Data size 16bit Data format DEC
Modbus address 1780,1781 CANopen address 0x235A,0x00
6.5 Extension and application (P4)
6.5.1 Communication setting
P4.01
1
485 local communication
address
Setting range Default Unit Available mode
1~255 1 - P S T F
This parameter is used to set local (slave) communication address of 485 serial communication.
P4.01
1
Data size 16bit Data format DEC
Modbus address 1802,1803 CANopen address 0x2401, 0x00
P4.02
1
CAN communication baud
rate
Setting range Default Unit Available mode
0~5 1 - P S T F
This parameter is used to select CAN communication baud rate. Available baud rate are as
follow:
Setting value Baud rate
0 1000kbps
[1] 500kbps
2 250kbps
3 125kbps
4 50kbps
5 20kbps
P4.02
1
Data size 16bit Data format DEC
Modbus address 1804,1805 CANopen address 0x2402, 0x00
P4.03
1
485 communication baud
rate
Setting range Default Unit Available mode
0~3 1 - P S T F
This parameter is used to select 485 communication baud rate. Available baud rate are as
follow:
Setting value Baud rate
0 9600bps
[1] 19200bps
2 38400bps
3 57600bps
P4.03
1
Data size 16bit Data format DEC
Modbus address 1806,1807 CANopen address 0x2403,0x00
P4.04
1
485 communication parity
mode
Setting range Default Unit Available mode
0~5 0 - P S T F
