INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Faults and solutions
‐134‐
1
Negative
polarity
[+voltage] → [negative],[- voltage] → [positive]
P3.74
Data size 16bit Data format DEC
Modbus address 1748,1749 CANopen address 0x234A,0x00
P3.75
Voltage protection of
analog input 3
Setting range Default Unit Available mode
0.000~10.000 0.000 V P S T F
This parameter is used to set the overvoltage protection value of analog input 3.
If the absolute value of analog input 3 voltage exceeds the set value, the system will report
alarm.
P3.75
Data size 32bit Data format DEC
Modbus address 1750,1751 CANopen address 0x234B,0x00
P3.76 Analog input 3 filter
Setting range Default Unit Available mode
0.0~1000.0 0.0 ms P S T F
This parameter is used to set the time constant of first order low-pass filter of analog input 3.
P3.76
Data size 16bit Data format DEC
Modbus address 1752,1753 CANopen address 0x234C,0x00
P3.77
Deadzone mode of
analog input
Setting range Default Unit Available mode
0~1 0 - P S T F
Set the deadzone voltage mode of analog input by this parameter
Setting value Definition
[0] Normal mode
1
CNC mode. When AI is smaller than the deadzone, the valid value is 0:
When AI is larger than the deadzone, the valid value is AI-deadzone.
P3.77
Data size 16bit Data format LIST
Modbus address 1754, 1755 CANopen address 0x234D, 0x00
P3.90 Pulse input filter
Setting range Default Unit Available mode
0~7 2 - P S T F
This parameter is used to set filter time of the pulse input.
Setting value Width of pulse input
0 400kHz
1 500kHz
[2] 1MHz
3 2MHz
4 4MHz
5 >4MHz
6 200kHz
7 100kHz
