INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Product overview
‐9‐
Symbol Instruction Naming instance
① Product series For internal use by manufacturer
② Encoder cable EL: Encoder cable
③ Cable number
06: 6-core cable
09: 9-core cable
15: 15-core cable
④ Cable length
03: 3m
05: 5m
10: 10m
……
⑤ Plug on motor end
A: 15PIN DB plug
B: 15PIN regular aviation plug YD28
C: 9PIN metal plug
D: 6PIN plastic head
⑥ Cable material
0: regular cable without battery holder
D: regular cable with battery holder
F: Flexible drag chain cable without battery holder
H: Flexible drag chain cable with battery holder
⑦ Encoder type
01: 2500-PPR standard incremental type
04: 17-bit single-turn/17-bit multi-turn/23-bit multi-turn
absolute value
07: Rotary transformer
⑧ Serial no.
00: Standard part
01: Serial no. for non-standard part
……
1.3.5 Naming of encoder cables fittings
Symbol Instruction Naming instance
① Product series For internal use by manufacturer
② Encoder cable EL: Encoder cable
⑨ Plug on drive end A: 15PIN DB plug
⑤ Plug on motor end
A: 15PIN DB plug
B: 15PIN regular aviation plug YD28
C: 9PIN metal plug
D: 6PIN plastic head
